BG Series 35W Mixer / Amplifier

SKU: 656726 · Model: BG-235 CU

$435.75

In Stock (1 available)

Free shipping on orders over $150

Authorized dealer — genuine products

•Massive Power supply for high-quality, reliable sound

•All inputs and outputs on removable Euro-block connections for easier installation

•Five year warranty

•Mic/Line 1 w/ Balanced phoenix input and Manual Mute Trigger

•Line 2 w/ Phoenix&RCA summing connector

•Line 3 w/ Phoenix&RCA summing connector

•Input 1 selectable between Mic/Line input level

•MOH/Zone2 balanced line output assignable via rear-panel dip switches. Selects any or all three input channels-no muting. Can be used for Music on Hold or 2nd Zone

•Mute receive assignable for channels 2&3 on rear-panel dip switches

•Mute can be activated via “VOX” or “Contact In” signal

•Mute Sensitivity and MOH/Zone 2 are both level adjustable

• Power outputs available at 4 Ohm, 25V&70V for more system flexibility

•Unbalanced Line Output can be used for an extra zone or for recording

•Dedicated Bass&Treble controls (recessed on front panel) allow independent adjustment for main output

•Thermal Overload Protection circuit with rear panel reset breaker

•Input Signal present, Peak&Power On indicators on front panel

•Optional Rack-mount kits for single unit (MB-25B-BK), or dual (MB-25B-J)

•Supplied security caps (YA-920 x 3) for volume knob to prevent unauthorized adjustment

•UL/cUL Listed

Weight: 10.14 lbsDims: 13.7″ × 11.3″ × 4.84″

Product Details

THE TOA BG-200 SERIES MIXER/AMPLIFIERS are ideal solutions for installations in restaurants, retail stores, lounges, classrooms and meeting rooms. Incorporating TOA's no-compromise technology, the new BG-200 Series are designed to provide the high performance and audio quality with wide frequency response, low noise and distortion and stable output regulation. The BG-200 Series Mixer/Amplifiers is comprised of two models: BG-220 (20W) and BG-235 (35W). Both models offer a simple and cost-effective solution for adding powered zones to an existing system as well as powering speakers in applications that require a line input from a mix or playback source. Using the perfected amplifier technology and bullet-proof construction that has made TOA an industry standard, the BG-200 Series Mixer/Amplifier is designed to make sound projects affordable, reliable and easy to install. The BG-200 Series Amplifiers are UL/cUL approved, competitively priced and is backed by TOA's 5 year warranty.
